T System Internal Diameter Turning Tools

Ordering Code	Item Designation	Dimensions									Master Insert	Barcode
	TD-NR/L (62.5)	Diamond Brand	d	h	L	f	D Min	Direction	Approach Angle	Weight (Kg)
SM04900	S25S TD-NR-11	ISO	25	23	250	19.5	≥36	Sağ	62.5°	0.95	DNM.1104..	8681408004900
SM04948	S25S TD-NL-11	ISO	25	23	250	19.5	≥36	Sol	62.5°	0.95	DNM.1104..	8681408004948
SM05068	S32T TD-NR-15	ISO	32	30	300	28	≥42	Sağ	62.5°	1.77	DNM.1506..	8681408005068
SM05143	S32T TD-NL-15	ISO	32	30	300	28	≥42	Sol	62.5°	1.77	DNM.1506..	8681408005143
SM05129	S40U TD-NR-15	ISO	40	37	350	32	≥52	Sağ	62.5°	3.4	DNM.1506..	8681408005129
SM05167	S40U TD-NL-15	ISO	40	37	350	32	≥52	Sol	62.5°	3.4	DNM.1506..	8681408005167
SM05037	S50V TD-NR-15	ISO	50	47	400	42	≥67	Sağ	62.5°	5.9	DNM.1506..	8681408005037
SM05198	S50V TD-NL-15	ISO	50	47	400	42	≥67	Sol	62.5°	5.9	DNM.1506..	8681408005198

T System Internal Diameter Turning Tools - TD-NR/L (62.5)
